BLDC Ceiling Fan Driver Card

BLDC Ceiling Fan Driver

BLDC Ceiling Fan Driver Card

  • Low THD (< 5%)
  • High PF(>95%)
  • Wide range of working (AC / DC)
  • High Speed (380+ RPM) at Low Power
  • Custom shapes and fitment arrangements




₹499.00

Clear
SKU: N/A Category: Tags: , ,

Description

Eyeing the constant changes in the ceiling fan industry and using our capabilities to design an Energy efficient solution, we designed our BLDC driver Cards for LV fan 1 phase & 3 phase motors in accordance to the Indian standards and requirements.

Our First batch of 10 thousand BLDC ceiling fan circuit board are already working in the field since the past 2 months as we supplied our maiden batch for evaluation. We have since then received inquiries and repeat orders from existing customers.We designed our first bldc ceiling fan circuit as a design service for a Delhi based Tier-2 customer,when EESL released its first tender and have constantly been perfecting the technology ever since.

Today, we have 3 variants of the BLDC ceiling fan control card
• Retrofit – Regulator Based Ceiling Fan Driver
• Comfort – IR Remote based Ceiling fan Driver
• Desire – IOT Enabled BLE/Wi-Fi controlled with Alexa and Google Home Integrated Fan circuit

Additional information

communication protocols

Bluetooth & IOT Base, IR Remote Base, Regulator Base

Specification and Features

Features



  • Solution ready as per new BEE ratings.
  • Energy Efficient – More than 70% Power Saving.
  • Card is compatible with all type of 3-phase BLDC Motors.
  • Consistent Speed from 110V to 260V AC.
  • Dual Input Working AC and DC.
  • LED and Buzzer Indication.
  • Easy Speed control using Smart Remote.
  • Over Voltage protection.

BLDC DRIVER CARD SPECIFICATIONS

  • Watt Up to                                :- 30W @370RPM
  • Supply voltage                         :- 230V / 0.18A
  • Frequency                                 :- 50 Hz ± 5%
  • DC Voltage & Current            :- 24V / 1.5 A
  • THD                                           :- < 5%
  • Supply Type                             :- Fly-Back Isolated
  • Motor                                        :- 3 Phase BLDC Sensor less
  • RPM                                          :- 370 ( Under Standard Test Condition )
  • Power Factor                           :- >0.95
  • Connection Type                    :- AC/DC
  • Tested                                       :- As per IES 61000-3-2
  • Communication Interfaces  :- Bluetooth (V5.0), Wi-Fi, IR Remote

Bluetooth Specifications

  • Bluetooth Version            :- 2.0 or higher
  • Connection range upto   :- 30mtr(with in room)
  • Reliable connection         :- within 10 millisecond
  • Androids Apps                  :- Available
  • Power consumption         :- Low

 Wi-Fi Specifications

  • Operating Voltage        :-  2.5 V ~ 3.6 V
  • B/G/N support             :- 802.11n support (2.4 Ghz), Up to 72.2 mbps
  • Automatic beacon monitoring (Hardware TSF)
  • Support Infrastructure :- BSS Station mode / SoftAP mode
  • Wi-Fi Mode                     :-Station/SoftAP/SoftAP+Station
  • Security                          :-  WPA/WPA2
  • Encryption                    :- WEP/TKIP/AES
